Description
Metso C80 & HP100 Crushing Circuit, Metso VGF & Sizing Screen, Modular Fabrication Conveyors, and more. Equip yourself with the gold standard.
Components & Inclusions
- Metso C80 Jaw Crusher
- Feed Opening: 800 x 510 mm (20″ x 32″)
- Closed Side Setting: 55 mm (2.17″)
- 75 KW Motor
- Metso HP100 Cone Crusher
- Standard Coarse
- Closed Side Setting: 16 mm (0.63″)
- 90 KW Motor
- Metso TKF8-32-2V Vibrating Grizzly Feeder
- 800 x 3200 mm (32″ x 10.5′)
- 2 Grizzly Sections in Cascade
- Spacing: 50 mm (2″)
- Grizzly Aperture: 37 mm (1.46″)
- Metso ES202 Vibrating Sizing Screen
- 1.87 x 4.9 m (6′ x 16′)
- Double Deck
- Top Deck Aperture: 38 mm (1.5″)
- Bottom Deck Aperture: 15 mm (0.6″)
- Modular Fabrication Truss Frame Conveyors
- 24″ x 58′ Transfer to Screen Deck
- 24″ x 46′ Cone Feed Conveyor
- 36″ x 25′ Heavy Duty Under Jaw Sacrificial Conveyor
- 24″ x 78′ Discharge Conveyor
- 24″ x 46′ Recycle Conveyor
- Eriez MG-165 Self Cleaning Electromagnet
- 36″ x 48″ x 23″
- Includes Rectifier
- MDI XR-36-S Metal Detector
